Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FRONT FENDER

FRONT FORK (CR500RS / RT / RV) FOR HONDA CR 500 R 1995

FRONT BRAKE CALIPER

FRONT FORK (CR500RS/RT/RV) Honda MOTO 500 CR 1995 CR500RS
1
CLAMPER A, FR, BRK.
CLAMP A, FR. BRAKE CABLE

45461-KA3-710   45461KA3710

45461KA3710

Unit Price Incl. Tax

2
CLAMPER B, FR.BRK.
CLAMP B, FR. BRAKE CABLE

45462-KA3-710   45462KA3710

45462KA3710

Unit Price Incl. Tax

3
FORK ASSY., R. FR. *R177R* *R177*

51400-MAC-681ZA   51400MAC681ZA

51400MAC681ZA
Contact
4
SPRING, FR. CUSHION (3.82N/MM, 0.39KGF/MM)

51401-MAC-681   51401MAC681

51401MAC681
Contact
4
SPRING, FR. FORK (KAYABA) (4.02N/MM, 0.41KGF/MM)

51403-KZ4-711   51403KZ4711

51403KZ4711
Contact
4
SPRING, FR. FORK (4.22N/MM, 0.43KGF/MM)

51403-MAC-681   51403MAC681

51403MAC681
Contact
5
GUIDE, SPRING

51404-KZ4-711   51404KZ4711

51404KZ4711
Not available
6
COLLAR

51405-KZ4-711   51405KZ4711

51405KZ4711
Contact
7
SEAT, SPRING

51408-KZ4-711   51408KZ4711

51408KZ4711
Contact
8
TUBE, OUTER

51410-MAC-681   51410MAC681

51410MAC681
Contact
9
RING, BACK UP
RING, BACK UP

51412-KZ4-711   51412KZ4711

51412KZ4711
Not available
10
BUSH, GUIDE
BUSH, GUIDE

51414-KZ4-711   51414KZ4711

51414KZ4711
11
BUSH,SLIDE
BUSH, SLIDE

51415-KZ4-711  

51415-KZ4-712
 51415KZ4711

Unit Price Incl. Tax

12
PIPE, R. SLIDE

51425-MAC-681   51425MAC681

51425MAC681
Contact
13
DAMPER COMP., FR.

51430-MAC-681   51430MAC681

51430MAC681
Contact
14
PLUNGER

51436-KZ4-711   51436KZ4711

51436KZ4711
Not available
15
COLLAR, REBOUND NEEDLE

51437-KZ4-711   51437KZ4711

51437KZ4711
Contact
16
BOLT COMP., CENTER

51441-MAC-681   51441MAC681

51441MAC681
Contact
17
RING,OIL SEAL STO<br />RING, OIL SEAL STOP
RING, OIL SEAL STO
RING, OIL SEAL STOP

51447-KZ4-711   51447KZ4711

51447KZ4711

Unit Price Incl. Tax

18
BOLT ASSY., FR.FOR
BOLT ASSY., FR. FORK

51450-KZ4-711   51450KZ4711

51450KZ4711
Not available
19
NUT, LOCK
NUT, LOCK

51451-KZ4-711   51451KZ4711

51451KZ4711
20
BOLT, PLUG
BOLT, PLUG

51456-KZ4-711   51456KZ4711

51456KZ4711
Not available
21
RING, WEAR
RING, WEAR

51476-KZ4-711   51476KZ4711

51476KZ4711

Unit Price Incl. Tax

22
SEAL SET, FR. FORK
SEAL SET, FR. FORK

51490-KZ4-305   51490KZ4305

51490KZ4305

Unit Price Incl. Tax

23
FORK ASSY., L. FR. *R177R* *R177*

51500-MAC-681ZA   51500MAC681ZA

51500MAC681ZA
Contact
24
PIPE, L. SLIDE
PIPE, L. SLIDE

51525-MAC-681   51525MAC681

51525MAC681
Contact
25
PROTECTOR, *R177R*
PROTECTOR, L. FR. FORK *R177R* *R177*

51610-ML3-600ZB   51610ML3600ZB

51610ML3600ZB
Contact
26
PROTECTOR, *R177R*
PROTECTOR, R. FR. FORK *R177R* *R177*

51620-ML3-600ZB  

51620ML3600ZB
Contact
27
BOLT, FLANGE, 6MM

90113-KZ3-000   90113KZ3000

90113KZ3000

Unit Price Incl. Tax

28
BOLT, PROTECTOR

90113-MAC-680   90113MAC680

90113MAC680

Unit Price Incl. Tax

29
WASHER, SPECIAL

90544-KZ4-711   90544KZ4711

90544KZ4711
Contact
30
DUST SEAL
DUST SEAL

91254-KZ4-711   91254KZ4711

91254KZ4711

Unit Price Incl. Tax

31
O-RING, 21.8X2.4

91256-KZ4-711   91256KZ4711

91256KZ4711
Contact
32
O-RING, 12.3X2.4

91257-KZ4-711   91257KZ4711

91257KZ4711
Not available
33
O-RING, 39.7X3.5

91258-KZ4-711   91258KZ4711

91258KZ4711

Unit Price Incl. Tax

34
O-RING, 19.5X1.5

91259-KZ4-711   91259KZ4711

91259KZ4711
Contact
35
O-RING, 2.8X1.9

91260-KZ4-711   91260KZ4711

91260KZ4711

Unit Price Incl. Tax

36
BOLT, FLANGE, 8X40

96300-0804008  

95701-0804008
 963000804008

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Honda, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Honda 1995 CR 500 R

Engine Frame

Honda 1995 CR 500 R

All the genuine spare parts for: CR Honda 500 1995

Color code : R177
500 CR 1995 CR500RS
Color code : R177

CR 500 R

Honda CR

Displacement: 500 cc
Year: 1995
Model code CR500RS
Color: R177
